Specification
| DC | |
| Cell | LFP 280Ah |
| Number of MPPT | 2 |
| MPPT Operating Voltage/Full Load Voltage | 250 - 850/450 - 850 |
| Protection | Circuit Braker and fuse |
| Pack Capacity /Arrangement | 14.336KWH / 1P16S |
| Maximum PV Input Voltage/Power | 1000V / 120kW |
| System Capacity /Arrangement | 215KWH/1P240S |
| Nominal Current | 140A |
| Charge/Discharge Rate | ≤0.5Cp |
| DC Efficiency | 0.94 |
| AC (On Grid) | |
| Nominal Output Power | 100kW |
| Nominal Input Voltage | AC340V~460V |
| Power Factor | -1~1 |
| Nominal Output Current | 144A |
| Nominal Grid Frequency | 50Hz/60Hz |
| Wiring | 3P+N+PE |
| AC (Off Grid) | |
| Nominal Output Power | 100kW |
| Nominal Input Voltage | AC400V |
| THD | Linear ≤1%/Nonlinear ≤5% |
| Nominal Output Current | 144A |
| Nominal Grid Frequency | 50Hz/60Hz |
| Output Wiring | 3P+N+PE (Isolated transformer, STS inside) |
| System | |
| Overall System Efficiency | 87%&0.5P (STD) |
| Communication | RS485, CAN, TCP/IP |
| Fire Prevention | FK5112 |
| DOD | 5-95% |
| Charging/Discharging Rate | ≤0.5Cp |
| Cooling Power | 1.1kW/3.0kW |
| Cooling | Forced air cooling |
| Operation Temperature | -20℃~50℃(>45℃ derating ) |
| Cabinet Enclosure Protection for Cabinet | IP54 |
| Relative Humidity Range | 5-95%RH (no condensing) |
| Noise | <75dB |
| Weight | 3900KG |
| Max. Operation Altitude | ≤3000M |
| Size (MM) | 2450L1550D2400H |
