Feature
Overview:Indoor battery rack with IP20 protection level,inbuild lithium-ion battery and BMS
Easy Installation And Maintenance:Local and remote management, standard rack&module design, front maintenance
Safety & Reliable:Self-developed 2-level / 3-level BMS,complex protection, safe and reliable
High Density:LP high-capacity Li-ion battery with aluminum shell, over 130wh/kg
Long Lifespan:Long cycle life, 6000 cycles
Cell Balancing Technology:Active cell balancing and passive cell balancing
| Performance | |
| Battery module (Wh/V) | 14.336 kWh, 51.2 V, 110 kg (242.5 lbs) |
| Number of modules | 14 |
| Cell technology | LFP (LiFePO4) |
| Battery usable energy [1] | 200.704 kWh |
| Nominal voltage | 716.8 V |
| Operating voltage | 638.4 - 786.24 V |
| Nominal output current | 140 A / 280 A |
| Communication | |
| Display | SOC status indicator, LED indicator, LCD display |
| Communication | Ethernet / CAN / RS485 |
| General Specification | |
| Weight | 1900 kg (4189 lbs |
| Dimension (W*D*H) | 1500x1050x2200 mm |
| 50.1x41.3x86.6 inch | |
| Operating temperature [2] | -20 to 60 °C (-4 to 140 °F) |
| Environmental humidity | ≤ 95%RH (No condensation) |
| Protection rating | IP 55 |
| Cycle life [3] | 6000 Cycles @ 80% DOD / 25℃ / 0.5C，60% EOL |
| Scalability | Yes |
| Application | ON Grid / ON Grid + Backup / OFF grid |
| Compatible PCS | Refer to compatible PCS list |
| Standard Compliance | |
| Certificates | Cell: UN38.3 / IEC62619 / UL 1642 / JET |
| Pack: UN38.3 / IEC62619 / IEC61000 | |
| System: UL 9540 (More available upon request) | |
[1] Test conditions: 100% depth of discharge (DoD), 0.2C rate charge & discharge at 25℃
[2] Charge/discharge derating occurs when the operating temperature from -10℃ to 5 ℃.& 45 ℃ to 55 ℃
[3] Condition apply. Refer to Warranty Letter
